2026 Haulmark TSV714T2 - 21143
Get in Touch
Description
2026 Haulmark TSV714T2
THERE'S A WIDE-WORLD OUT THERE. EXPERIENCE IT ALL!
In life, there are no shortcuts to success, and you never settle for second best. Fueled by relentless innovation, the Transport V-Nose is a value-packed combination of performance, durability, and low-maintainence. Our trailers defy the routine and are designed to dominate every type of cargo hauling activity. At Haulmark, we build trailers that work (and play) as hard as you do.
Features may include:
- 1-Piece Aluminum Roof
- Entire Chassis Undercoated
- 3/4" PlexCore High Performance Decking
- 3/8" PlexCore High Performance Sidewall
- 24" ATP Stoneguard
- 15" Radial Tires
- Silver Mod Wheels
- E-Z Lube® Hubs
- Spring Axles
- Rear Ramp Door with Spring Assist
- 5,000 lb. D-Rings with Welded Plate (4)
- Electric Brakes with Breakaway Kit
- 3-Year Limited Warranty
- ArmorTech on A-Frame and Rear End Rail
- .030 Aluminum Exterior - Bonded (Smooth Appearance)
- 36" Side Door w/ Flush Lock
- Smooth Aluminum Radius Fenders
- LED Mini Clearance Lights
- 12v LED Dome Light with Wall Switch
- 2" x 3" Tube Main Rails (Single Axle)
- 2" x 4" Tube Main Rails (Tandem Axle)
- 16" OC Floor Crossmembers
- 16" OC Tube Vertical Posts
- 16" OC Tube Roof Structure
- PlexCore Ramp Extension
- 3.75" Wide Extruded Aluminum Top Trim
Dealer Notes
2026 Haulmark Transport Enclosed Trailer
Steel Frame
14ft Long
Flat Roof
7ft Wide
2-5/16in 14,000lb Coupler
Crossmembers 16in On Center
2in x 4in Tube Main Rails
V-Nose
Tube Roof Bows 16in On Center
8/0 x 27" G3 Safety Chains with Slip Hook
7'0" Approximate Inside Height
80-3/4in Tube Posts
Vertical Posts 16in On Center
Sand Pad
2,000lb Top Wind Tongue Jack
Standard A-Frame Tongue
ArmorTech on A-Frame and Rear End Rail
Breakaway Kit Assembly w/Charger
3.5K Spring Ele Brake Axle, 4in Drop,5b,EZ Lube
Tandem Axle
ST205/75R15 Radial 5B Silver Mod Steel Wheel
Chrome Center Caps on Wheels
Medium Duty Rear Ramp Door (8'H Max) w/Ramp Extn.
36 x 78 Side PT Door - RH Hinge
3/4in PlexCore Decking
3/8in PlexCore Sidewall Liner
5,000lb Square D-Ring with Welded Plate
12 Volt LED Dome Light (Requires 12v Wall Switch)
License Plate Holder w/ Separate Light
LED Fender Mount Clearance Lights
LED Slim Line Clear Lens Tail Lights
LED Clear Lens Amber Clearance Lights
LED Clear Lens Red Clearance Lights
LED Clear Lens Rear Clearance Light ID Bar
12v Surface-Mount Switch
1-Piece Aluminum Roof
Bonded Exterior Sidewalls
Smooth Aluminum Fenders
24in ATP Stoneguard
Sidewall Flow-Thru Vents
Black .040
12in Fold-Down Stabilizer Jacks
Info
Industry
Trailer
Make
Haulmark
Model
TSV714T2
Trim
Base
Year
2026
Price
8795.00
Stock Number
21143
Category
Cargo / Enclosed Trailer
Subcategory
Cargo / Enclosed Trailer
Condition
New
Location
Washington, NJ
Vin
7V0H11428TP421143
Dry Weight
2,125 lbs
Color
Black
Hitch Type
Bumper
Axles
2
Length
168 in
Width
84 in
Gvwr
7,000 lbs
Payload Capacity
4,875 lbs
Trailer Material
Steel Frame / Aluminum Skin
Specifications
Length
Overall: 18 ft 0 in | Body: 15 ft 6 in | Interior: 15 ft 3 in
Width
Overall: 8 ft 6 in | Body: 7 ft 0 in | Interior: 6 ft 9 in
Height
Overall: 8 ft 2 in | Interior: 6 ft 6 in | Platform: 18"
Axles
Tandem | 7,000 lbs
Tires
ST205/75R15
Hitch Size
2 5/16 in | Height: 17 in
Dry Weight
Curb: 2,125 lbs.
GVWR
7,000 lbs.
Max Load
Payload: 4,875 lbs.
Gate/Door
Rear Door W x H: 78 in x 72 in | Pass-Thru: 36 in x 72 in
